LPH14 3 way Control Valve

LPH14 3 way Control Valve

LPH14 3-way control valve with mixing or diverting type trim and pneumatic or electric actuator

LPH11 Diaphragm / Piston Single Seat Control Valve PDF catalogues


  1. Compact structure, fewer parts, light weight
  2. Simple to wiring, easy to operate
  3. Regulating performance, accurate flow coefficient
  4. Small pressure loss, large flow capacity, low noise
  5. Small unbalanced force, allowing large pressure


Actuator Pneumatic, Pneumatic+Handwheel
Control On-off, Modulating, Inteligent
DN 25~300mm
Pressure PN1.6~25.0Mpa, ANI150~1500Lbs, JIS10~100K
Temperature Std: -20~200°C, -40~250°C, -60~250°C
Cooling type: -40~450°C, -60~450°C
Ambient temperature -20~55°C
Flow characteristics Straight line, Equal percentage
Inherent rangeability 30:1
Gas supply 0.14~0.3Mpa
Input signal 4~20MA, 1~5V
Output signal 4~20MA, 1~5V
Connection Flange
Structure Standard Type, Bellows Seal Type, Cooling Type
Body & Cap Material WCB, WCC, WC6, CF8, CF8M, CF3, CF3M
Stem Material 304, 316, 316L 17~4PH
Spool Material 304, 316, 316L, 17~4H, Surfacing Stellite
Packing Material PTFE, RTFE, Flexible graphite
Medium Gas, Water and Oil, etc
Option Limit Switch, Positioner, Solenoid Valve, Pressure-relief Valve
Remark Commissioning has been completed in the factory
connected to the gas source and the input signal can be used
