API standard Valves

API 608 Side Entry Floating Ball Valve

API 608 Side Entry Floating Ball Valve

API 608 Side Entry Floating Ball Valve, Soft Seat API Ball Valves

API 6D Soft Seat Ball Valve PDF catalogues

Design Feature

  1. Pressure class: Class 150 to Class 2500
  2. Size Range: 1/2" to 8"
  3. API standard 608
  4. ASME B16.34

 Structural Features

  1. Special seat design
  2. Fireproof structure design
  3. Anti static structure
  4. Reliable sealing of valve stem
  5. Lock and misoperation prevention

Cast Steel and forged steel material are available, customizied size maximum to DN400 (16") and CL4500.


Actuator Electric, Pneumatic, Electro-hydralic, Manual
Control On-off, Modulating, Inteligent
DN 2"~8"
Pressure ANSI CL150~CL2500
Temperature NYLON, DEVLON: <80°C
PTFE: <150°C
PEEK, PPL: <250°C
Connection Flange, Weld, Thread
Structure 2-pieces or 3-pieces Type
Body Material SS316L, SS316, SS304, SS304L, WCB, CE3MN, etc
Ball Material SS316L, SS316, SS304L, CE3MN, etc
Sealing Material Nylon, Devlon, PTFE, PEEK
Medium Gas, Water and Oil, etc
Option Limit Switch, Positioner, Solenoid Valve, Pressure-relief Valve

Pneumatic API 608 Side Entry Floating Ball Valve
