LPB17 Aeration Butterfly Valve | Damper Butterfly Valve

Aeration Butterfly Valve, Damper Butterfly Valve

Uses the center-line type structure
Easy installation, low flow resistance, large circulation
Applied to chemical, building materials, power station, glass industry etc
Small flow resistance, high turnover
Temperature up to 1100°C
Sealing performance up to 1%
Medium can flow through the body directly for little resistance and high flow capacity
The body and cover could be made of carbon steel,austenitic stainless steel or special alloy material
The sulfur-free flexible v-graphite is heat resisting ,we shall ensure the service life of packing is long-term without maintenance by increasing pre-pressure on spring gasket
Center line-type butterfly valve uses metal sealing seat,which surrounds the disc to reduce the leakage effectively

Body: The body is welded by steel plate for lighter weight .smaller volume,lower cost,and choosing high temperature resistant material can withstand higher
temperature.
V type packing: The sulfur-free flexible v-graphite packing overcomes the faults of normal packing including zero compensation and large deformation,
prolongs the service life, and is able to with stand high temperature.
Seat: The seat ring can reduce leakage and ensure the disc close to 0°.
Disc: The disc is made of steel plate,and stiffeners in both sides can make it withstand deformation due to wind effectively.
Ring: The ring has a location effect,which makes the disc turn in the middle of channel.

Actuator	Electric, Pneumatic, Handwheel, Handle
Control	On-off, Modulating, Inteligent
DN	100~1200mm
Pressure	0.01~1.0Mpa
Temperature	-196~1100°C
Connection	Flange, Wafer
Structure	A Type
Body Material	SS316L, SS316, SS304, WCB
Disc Material	SS316L, SS316, SS304, WCB
Seat Material	NO
Medium	Dusty gas, Flue Gas, Gas
Option	Limit Switch, Positioner, Solenoid Valve, Pressure-relief Valve
