LS10 Limit Switch - Lapar Valve
LS series limit switch box provides a compact design and the most economical solution for both visual and remote electrical indication of rotary valve/actuator position. Integral NAMUR mounting legs provide additional cost saving by eliminating the need for a separate mounting bracket. The switch options available make the LS series suitable for use in IP65 weather proof applications and also intrinsically safe applications.
- LS10 Electronic SPDT silver-plated contact body
- LS11 Electronic SPDT gold-plated contact body
- LS12 Proximity PNP NO P + F V3 E2 NBB2
- LS13 NO / NC proximity programmable instruct flowmeter IS5026
- LS14 Proximity NO P + F NBB3 V3 Z4
Feature
- Automatic control accessories
- Easy to install and operate
- Clear instructions, easy to identify
- Local 3D position indicator
Parameter
| Material | Enhanced Polymer, Fasteners: Stainless steel |
| Working Temperature | -20~80°C |
| Switch | Mechanical E-Switch x 2, Induction P+F x 2 |
| Protection class | IP65, NAMUR4 and 4X |
| Stand | Inside 80 x 20~50, Outside: 130 x 20~50 |
| Local Display | 3D |
| Cam angle | 3°/360° |
| Rating | (Resistive load) Min 50MA; Max 5A@250V AC, 5A@110V AC, 3A@24V DC |
| Cable Connection | 1/2NPT |
LS10 Limit Switch Dimensions
