LPH33 Angle Type High Pressure Cage Guided Control Valve

LPH33 Angle Type High Pressure Cage Guided Control Valve

LPH33 Angle type high pressure cage guided control valve with pneumatic or electric actuator

Angle type hight pressure cage guided control valve PDF catalogues

Feature

  1. Compact structure, fewer parts, light weight
  2. Low pressure drop, large flow rate
  3. Adjusted performance, small pressure loss, flow ability
  4. Leakage rate meets ANSI B16.104 standards, multi-spring diaphragm actuator has compact structure large output force

Parameter

ActuatorPneumatic, Pneumatic+Handwheel
ControlOn-off, Modulating, Inteligent
DN40~200mm
PressureANSI900~2500Lbs, JIS63K
TemperatureStd: -5~230°C
high temp: 230~566°C
Flow characteristicsLinear, Equal percentage
Inherent rangeability50:1
ConnectionFlange, Welding
