LPI12 Self-operated Temperature Control Valve

LPI12 Self-operated Temperature Control Valve

LPI12 Self-operated Temperature Control Valve

LPI12 Self-operated Temperature Control Valve PDF catalogues

LPI12 self-operated temperature(heating type/cooling type)control valve is composed of the control valve and a temperature controller provided with fixed point control.

t is suitable for controlling differential pressure in the pipes of non-corrosive liquids,gases and steams.when the temperature of the controlled mediums rises,the control valve is closed.

The main features are as follows:

  • It has the pressure balancing function with high sensitivity.
  • Low noise, reliable performance, free of maintenance.
  • The standard modular design is adopted.
  • It adopts the imported fixed point controller which has the over temperature protection function with reliable quality.
  • Various combined controls can be carried out through the assemblies.
Size DN15~250
Pressure Rating PN16, 25, 40
Pressure Balance Devices Bellows, Cage
Characteristics Quick Opening
Temperature Set Range 40~100
Allowable Overload With 20% of the setting value
Leakage Class IV
