Plastic Diaphragm Valve
Design Feature
- For highly contaminated medium
- Any direction of medium flow
- Good sealing performance
- Designed to be lightweight and good circulation
Parameter
| Actuator | Pneumatic, Handwheel |
| Control | On-off, Modulating |
| DN | 15~50mm |
| Pressure | 1.0Mpa |
| Temperature | UPVC: 0~60°C CPVC: 0~90°C PP: 0~80°C |
| Connection | Wafer, Plastic Welding, Union |
| Body Material | UPVC, CPVC, PP |
| Diaphragm Material | FPM, EPDM, NBR |
| Plug Material | Casting Iron, PP |
| Medium | Gas, Water treatment and Oil |
| Option | Limit Switch, Positioner, Solenoid Valve, Pressure-relief Valve |
