LPC14 Sanitary Control Valve

LPC14 Sanitary Control Valve

Sanitary Control Valve

LPC14 Sanitary Control Valve PDF catalogues

Design Feature

LPC14 Pneumatic adjusted seat valve apply for high sanitary technics process of strictly control flow and pressure. And use filing system of measurement, mixture and metage. Mainly for dairy, beverage, food, biology, pharmacy and cosmetic, etc.

Parameter

Actuator Pneumatic, Handwheel
Control On-off, Modulating, Inteligent
DN 40~100mm
Pressure 0~6.3Mpa (Accepting High Pressure Requirement)
Temperature Working Temperature: -29℃~150℃
Sterilization Temperature: 150℃(Max 20Min)
Connection Standard :Welded End( DIN 11850 series 2), Welded End (INCH Ripe standard)
Connection: Weld, Thread, Clamp, Flange
Structure Standard Type, Low temperature
Bellows Seal Type, Cooling Type
Metal material Contact Product Part: 304/316/316L (1.4404)
No-contact Product Part: 304/316/316L (1.4301)
Provide EN 10204.3.1B certificate
Sealing Material Standard: PTFE
Option:BODY, STL
All Seal material coply with FDA 177.2800
Surface Treatment Internal Surface: R≤0.8um
External Surface: Standblasting
Medium Food, Beverages, Cosmetic, Wine, etc
Option Limit Switch, Positioner, Solenoid Valve, Pressure-relief Valve
