LPA16 Thin Ball Valve

LPA16 Thin Ball Valve

Thin Ball Valves, Italy Type Ball Valve

LPA16 Thin Ball Valve PDF catalogues

Design Feature

  1. Anti Blow-Out Stem
  2. Antistatic Device
  3. Fire Safe Design
  4. Soft Seated or Metal Seated
  5. Low Fugitive Emission
  6. Double Block and Bleed
  7. Welded or Bolted Body
  8. Self Relieving Seats or Double Piston Effect
  9. Extended Stem
  10. Cryogenic Extended Bonnet
  11. Lost-wax precision casting
  12. Fire Safe Design approved
  13. Built-in ISO5211 direct mounting pad for easy automation
  14. Anti-static devices for ball-stem-body
  15. Blow-out proof stem
  16. TA-LUFT design approved

Severe application

  1. Corrosive
  2. Erosive
  3. High Temperature
  4. Cryogenic
  5. Underground
  6. Subsea
  7. Other Special Requirements

Material

  1. Carbon Steel
  2. LT Carbon Steel, Impact Tested
  3. Ferritic/Austenitic Stainless Steel (Duplex - Super Duplex)
  4. Austenitic Stainless Steel
  5. Austenitic Stainless Steel (6Mo)
  6. Hardened Stainless Steel - Precipitation
  7. Martensitic Stainless Steel
  8. High Strength Low Alloyed Steel
  9. Non-Ferrous Steel, Nickel Alloy
  10. Titanium
  11. Exotic Materials

Standard

  1. Design: DIN 3357/1.2, EN12516-1
  2. Flanged End: DIN EN1092-1 PN10-PN40
  3. Inspection & Testing: DIN 3230/3, EN12266
  4. Fire Safe: API 607 5th2005, IOS 10497

Parameter

ActuatorElectric, Pneumatic, Handwheel, Handle
ControlOn-off, Modulating, Inteligent
DN15~150mm
Pressure1.6~4.0Mpa
TemperaturePTFE, TFM1600: -29~178°C
EK: -29~250°C
ConnectionFlange, Wafer
StructureOne-piece
Body MaterialSS316L, SS316, SS304, SS304L, WCB
Ball MaterialSS316L, SS316, SS304, SS304L
Sealing MaterialPTFE, TFM1600, EK
MediumGas, Water and Oil, etc
OptionLimit Switch, Positioner, Solenoid Valve, Pressure-relief Valve
